FAW 2-Axle / 3-Axle / 4-Axle Grain Trailer

FAW grain trailer is a trailer pulled by a truck tractor and used to haul bulk commodity products, such as grain. These trailers are used extensively throughout Africa to transport agricultural products as well as any other commodity that can be hauled in bulk and loaded and unloaded through the trailer.

Specification	Details
Dimensions (mm)	12,500 × 2,800 × 3,260
Trailer Sides Height (mm)	1,200
Loading Capacity (t)	≤ 50
Axles	13 / 16 t, FUWA / BPW / Brand
Tires	12 Units, 12.00R22.5 or 315/80R22.5
Rim	9.00-22.5 or 9.75-22.5
Suspension	Mechanical Suspension / Air Suspension
Spring Leaf (mm)	90 (W) × 13 (Thickness) × 10 Layers or 100 × 12 × 12
Kingpin	JOST 2.0 or 3.5 inch (bolted or welded)
Landing Gear	JOST D200T or Chinese Brand, 28 Tons (Double-Speed)
Main Beam (mm)	Height: 500; Upper Plate: 14 mm; Middle Plate: 8 mm; Bottom Plate: 16 mm
Valve	WABCO RE 6 Relay Valve; T30/30 + T30 Spring Brake Chamber (TKL Brand)
