FAW SWING ARM GARBAGE TRUCK is equipped with a hydraulic lifting assembly. The swing-arm garbage
The bucket is transported through the left and right arms. It can have multiple buckets in one truck and has a self.
It can have multiple buckets in one truck and features a self-unloading function, ensuring safer operation, stable performance, and reliable waste collection efficiency in urban sanitation and municipal applications.
| Parameter | Specification |
|---|---|
| Drive System | 4×2 |
| Cabin | FAW J5K cab, one and a half row seats, electronic flameout, with air conditioning |
| Engine | WEICHAI / YUCHAI / FAWDE |
| Rated Power | 290 HP |
| Gearbox | CA6TB085M, 6 forward speeds, 1 reverse speed |
| Clutch | Single-plate dry diaphragm spring clutch |
| Front / Rear Axle (kg) | 4000 / 8000 |
| Volume | 10 CBM |
| Shape | Round |
| Material | Carbon Steel (with anti-corrosion paint) |
| Function Introduction | 1. 6-metre suction hose 2. One rear artesian flow hose 3. Hydraulic dumping function 4. Rear door hydraulic opening 5. Ladder: For access to the top of the tank, complete with a walk on top of the tank 6. One manhole |
