| Vehicle Type | CA4250 |
| Drive Mode | 6X4 |
| Cab | JH6, Flat Floor, High Roof, LHD |
| Engine Model | WP13N G430E52 / WP12N G400E50 |
| Displacement | 12.54 L |
| Maximum Power | 316 kW / 1900 rpm |
| Maximum Torque | 2000 N·m / 1100–1400 rpm |
| Emission | Euro V |
| Transmission Model | ZF16S2321 TO / C16JSDQXL220TA |
| Transmission | Manual, 16-speed |
| Forward Gear Ratio Range | 12.80–0.84 |
| Front Axle Load | 7,000 kg |
| Front Suspension | Parabolic Leaf Spring |
| Rear Axle Load | 2 × 13,000 kg |
| Rear Suspension | Air Suspension |
| Rear Axle Model / Speed Ratio | 457 (i=4.444) / 435 (i=4.875) |
| Chassis Self Weight | 9,320 kg |
| Towing Weight | 49,000 kg |
| Wheelbase | 3800 + 1350 mm |
| Saddle | 50 |
| Tires | 315/80R22.5-20 |
| Brake System | Dual-Circuit Air Braking / ABS / Retarder |
